Amplifier Research 80S1G4 The Amplifier Research 80S1G4 is a solid state, self-contained, air-cooled, broadband amplifier designed for applications where instantaneous bandwidth, high gain, and linearity are needed. It is housed in a stylish cabinet and designed for benchtop use, but can also be removed for equipment rack mounting as well. Features and Specifications of the Amplifier Research 80S1G4 include:
Features:
Provides a minimum of 80 watts of RF power when used with a sweep generator
Front panel gain control allows the convenience of setting desired output level
RF input leveling circuit:
Controls the RF input level to the RF amplifier first stage when the RF input level is increased above 0 dBm
Protects the amplifier from RF input overdrive
RF amplifier stages are protected from over-temperature by removing the DC voltage to them if an over-temperature condition occurs due to cooling blockage or fan failure
Digital display on the front panel indicates the operate status and fault conditions when an over-temperature or power supply fault has occurred
All control functions and status indications are available remotely in GPIB/IEEE-488 format, RS-232 hardwire and fiber optic, USB, and Ethernet
Bus interface connector on back panel
Local/Remote switch on front panel assures positive control of local or remote operation
Low level of spurious signals and linearity make it ideal for these various uses:
As a driver amplifier in testing wireless and communication components and subsystems
As a test instrument covering multiple frequency bands
For communication technologies including: CDMA, W-CDMA, TDMA, GSM, etc.
For EMC test applications where undistorted modulation envelopes are desired
Specifications:
Rated power output: 80 watts minimum
Input for rated output: 1.0 milliwatt maximum
Power Output@ 3dB compression:
Nominal: 95 watts
Minimum: 68B compression:
Nominal: 85 watts
Minimum: 70 watts
Flatness:
Typical: ±1.5 dB
Maximum: ±2.0 dB
Frequency response: 0.7 – 4.2 GHz instantaneously
Gain (at maximum setting): 49 dB minimum
Gain adjustment (continuous range): 10 dB minimum (4096 steps remote)
Input impedance: 50 ohms, VSWR 2.0:1 maximum
Output impedance: 50 ohms, nominal
Mismatch tolerance:
100% of rated power without foldback
Will operate without damage or oscillation with any magnitude and phase of source and load impedance
Modulation capability: Will faithfully reproduce AM, FM, or pulse modulation appearing on the input signal
Third order intercept point: 58 dBm typical
Noise Figure: 10 dB typical
Harmonic distortion: Minus 20 dBc maximum at 80 watts
Spurious: Minus 73 dBc typical
Phase Linearity: ±1.0 deg/100 MHz typical
Noise figure: 10 dB typical
Primary power (selected automatically):
90-132, 180-264 VAC
50/60 Hz, single phase
448 watts maximum
Connectors:
RF: Type N female
Remote interfaces:
IEEE-488: 24 pin
RS-232: 9 pin Subminiature D
RS-232 (fiber optic): Type ST
USB 2.0: Type B
Ethernet: RJ-45
Safety interlock: 15 Pin Subminiature D
Cooling: Forced air (self contained fans)
